HDPE seamless winding tank installation and placement method

Views: 0     Author: Site Editor     Publish Time: 2022-03-25      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

After purchasing the HDPE seamless winding tank, the following task is also to lay out the winding tank. However, since PPH winding tanks are mainly used for holding compounds, there are certain regulations for the winding tanks for better safety, which will be introduced below.

Here is the content:

l Placement area

l Height

l Product tank area

Placement area

1, The grouping of the tank area should be fully satisfied with the total process flow of the whole plant and the general plan of the whole plant library placement standards.

2, Winding storage tank area should generally be placed alone in a district. But can be placed in the same block with the relevant oil pump room. The operator's tour inspection operation is also more convenient.

3, Refrigerated or non-refrigerated HDPE spiral wound tanks should be set in areas with outstanding ventilation and drainage.

Height

1, To confirm the root elevation of the chemical tank spiral wound HDPE area, should be fully satisfied with the provisions of the net suction head of the pump in the pump room associated with it.

2, The height from the low point of the spherical tank to the ground should be at least 1.5m to adhere to the outstanding ventilation around the spherical tank. For the bottom outlet of the ball tank, this height must be considered together with the pump's net positive suction pressure head (NPSH) before making a decision.

3, Material tank area and intermediate material tank area, the location should be as close as possible to the production equipment associated with it. And the planning ground elevation of the HDPE spiral wound tank area should be as high as possible or equal to the planning ground elevation of the production equipment.

Product tank area

1, The orientation of the product tank area should be as close as possible to the oil loading equipment. If it is the outbound transportation of the oil pipeline, the product tank area should be as close as possible to the first station of the outbound pipeline, to satisfy the provisions of the outbound transportation of products in time.

2, Chemical tank spiral wound HDPE area, should be placed close to the unloading equipment and should be placed in an area with the chemical transfer pump room. If chemicals are transported into the plant by car tanker, the chemical PPH winding storage tank area, pump room and unloading truck can be placed in one area, such as lye, acid, ammonia, etc.

3, Additive class tank area, it is appropriate to be close to the use of additives placed in the equipment, such as additives for lubricants, etc.

Our company is a leading HDPE spiral wound tanks manufacturer and exporter, following the corporate philosophy of excellent quality, reasonable price, and perfect after-sales service. Relying on superb research and development and advanced manufacturing technology, we provide our customers with the safest products and help them explore the market. And win the wide praise from our customers Our products are all over the world, covering several customers, including distributors and end-users.
