PP-H Chemical Storage Tanks Machine

 HDPE spiral tank machine

Eagle Co developed the special HDPE/PP-H chemical storage tank winding machine and associated equipment. The main thermoplastic spiral tank winding machine consists one or two extruders. It can produce a continuous molten band of polyethylene (HDPE) or polypropylene (PP). The melt band is wound on a pre-heated steel mandrel to produce a seamless spiral tank shell. The shell diameter can be upto 5meters, length can be upto 8meters. This process can produce the spiral tank shell upto 110mm.

HDPE/PP Spiral Wound Tank

The automatic tank bottom welding machine can weld the bottom with HDPE/PP-H spiral tank shell with very strong welding seam.

HDPE spiral tanks machine

The HDPE/PP-H spiral tank machine, automatic tank welding machine and other associated equipment can produce the tank with the capacity more than 100m3 designed and manufactured according to EN12573 and DVS 2205.





Capacity of round tanks (upright) in

DN \ H

4000

5000

6000

7000

8000

9000

10000

11000

12000

1000

3,1

3,9

4,7

5,5

6,3

7,1

7,9

8,6

9,4

1200

4,5

5,7

6,8

7,9

9,0

10,2

11,3

12,4

13,6

1400

6,2

7,7

9,2

10,8

12,3

13,9

15,4

16,9

18,5

1600

8,0

10,1

12,1

14,1

16,1

18,1

20,1

22,1

24,1

1800

10,2

12,7

15,3

17,8

20,4

22,9

25,4

28,0

30,5

2000

12,6

15,7

18,8

22,0

25,1

28,3

31,4

34,6

37,7

2300

16,6

20,8

24,9

29,1

33,2

37,4

41,5

45,7

49,9

2400

18,1

22,6

27,1

31,7

36,2

40,7

45,2

49,8

54,3

2600

21,2

26,5

31,9

37,2

42,5

47,8

53,1

58,4

63,7

2800

24,6

30,8

36,9

43,1

49,3

55,4

61,6

67,7

73,9

3000

28,3

35,3

42,4

49,5

56,5

63,6

70,7

77,8

84,8

3400

36,3

45,4

54,5

63,6

72,6

81,7

90,8

99,9

109,0

3600

40,7

50,9

61,1

71,3

81,4

91,6

101,8

112,0

122,1

3800

45,4

56,7

68,0

79,4

90,7

102,1

113,4

124,8

136,1

4000

50,3

62,8

75,4

88,0

100,5

113,1

125,7

138,2

150,8
